ASV Rubber Track for Compact Track Loader | Replacement Rubber Tracks
ASV Rubber Track for Compact Track Loader
YIJIANG supplies replacement rubber tracks for ASV compact track loaders, with multiple track sizes covering compact and mid-size tracked loader applications. Available configurations include 9-inch, 10-inch, 11-inch, 14-inch, 15-inch and 18-inch track widths, with different pitches and link configurations. These rubber tracks are designed as replacement tracks for ASV equipment and can also be supplied according to specific machine and track specifications.
What ASV Rubber Track Sizes Does YIJIANG Supply?
| Rubber Track Specification | Inch Size | Track Width | Pitch | Link Count | Drive Lug Configuration |
|---|---|---|---|---|---|
| 218 × 64.55 × 50 mm | 9 × 3 × 50 | 218 mm | 64.55 mm | 50 | Standard |
| 250 × 88.2 × 28 mm | 10 × 3.5 × 28 | 250 mm | 88.2 mm | 28 | Standard |
| 280 × 102.1 × 37 mm | 11 × 4 × 37 | 280 mm | 102.1 mm | 37 | Standard |
| 360 × 101.6 × 28 mm | 14 × 4 × 28 | 360 mm | 101.6 mm | 28 | Standard |
| P381 × 100.3 × 51 mm | 15 × 4 × 51 | 381 mm | 100.3 mm | 51 | P-Type |
| 381 × 101.6 × 42 mm | 15 × 4 × 42 | 381 mm | 101.6 mm | 42 | Standard |
| C457 × 101.6 × 51 mm | 18 × 4 × 51 | 457 mm | 101.6 mm | 51 | 2-Tooth |
| YC457 × 101.6 × 56 mm | 18 × 4 × 56 | 457 mm | 101.6 mm | 56 | 3-Tooth |
Note: Track dimensions and configurations should be confirmed against the original machine track before ordering. The same track width may have different pitch, link count, or drive-lug configurations.
How Do You Identify the Correct ASV Rubber Track?
Choosing the correct replacement rubber track requires more than checking the track width.
Check the Track Width
Measure the overall width of the existing rubber track. The available YIJIANG sizes range from 218 mm to 457 mm.
Check the Track Pitch
The pitch is the distance between corresponding points on adjacent drive lugs. It should match the sprocket and undercarriage drive system.
Check the Link Count
The total number of links or pitches around the track is another important identification dimension. For example, the available 457 mm configurations include 51-link and 56-link versions.
Check the Drive Lug Configuration
Some rubber tracks have different drive-lug arrangements. The available 457 mm references include 2-tooth and 3-tooth configurations, so the drive system should be checked before ordering.
Why Choose YIJIANG ASV Replacement Rubber Tracks?
Multiple Track Sizes
YIJIANG offers multiple ASV-related rubber track configurations from 218 mm to 457 mm width.
Specification-Based Matching
Track width, pitch, link count and drive-lug configuration can be checked together to reduce the risk of ordering an incorrect track.
Replacement Track Manufacturing
As a crawler undercarriage and track component manufacturer, YIJIANG can support customers looking for replacement rubber tracks for compact tracked equipment.
How to Order ASV Rubber Tracks from YIJIANG?
To confirm the correct rubber track, please provide as much of the following information as possible:
Machine Information
• ASV machine model
• Compact track loader model
• Year of manufacture, if available
Existing Track Information
• Track width
• Track pitch
• Link count
• Drive-lug configuration
• Existing track part number, if available
Photos for Track Identification
Clear photographs of the inside of the rubber track, drive lugs and sprocket can also help YIJIANG identify the correct configuration.
Frequently Asked Questions About ASV Rubber Tracks
A: 2 PC.
A: Shanghai, Ningbo, Shenzhen, Qingdao or negotiated.
A: Yes. YIJIANG supplies replacement rubber tracks for ASV compact track loader applications in multiple sizes and configurations.
A: No. The 457 mm configurations can have different pitch, link count and drive-lug configurations. YIJIANG's current references include C457 × 101.6 mm / 51 links / 2-tooth and YC457 × 101.6 mm / 56 links / 3-tooth.
A: Provide the machine model together with the existing track width, pitch and link count. Photos of the track and sprocket are also recommended so the configuration can be checked before ordering.
A: Yes. YIJIANG currently lists 381 mm (approximately 15-inch) rubber tracks in two reference configurations: P381 × 100.3 mm / 51 links and 381 × 101.6 mm / 42 links.
A: The United States, Canada, Australia, Germany, South Korea, Uruguay, Denmark, Finland, and so on.
Request an ASV Rubber Track Quote
Looking for replacement rubber tracks for an ASV compact track loader?
Send us your ASV model, current rubber track size, pitch, link count, or track photos. YIJIANG can check the specification and provide the corresponding replacement rubber track solution.
