2 tons spider lift unilateral rubber track undercarriage

Short Description:

The rubber track undercarriage is specially designed for spider lift machinery.

It is unilateral ,the load capacity is 1-10 tons.

The unilateral design gives the robot host greater flexibility in size.

Send email to us

Product Detail

Product Tags

Product Details

The tracked undercarriage has a large grounding area, which strongly reduces the surface pressure and increases the stability of the machine.

With suitable rollers and driver, the lifting crane can be freely walked on the ground such as narrow passage and slope. The use of non-marking rubber crawler brings a bright color to the lift crane, and also can firmly adhere to the ground.

The structural parts of the undercarriage can be firmly connected with the lifting parts of the crane.

Product Parameters

Condition:	100% New
Applicable Industries:	Crawler Spider Lift
Video outgoing-inspection:	Provided
Place of Origin	Jiangsu, China
Brand Name	YIKANG
Warranty:	1 Year or 1000 Hours
Certification	ISO9001:2019
Load Capacity	2 Tons
Travelling Speed (Km/h)	0-5
Undercarriage Dimensions(LWH)(mm)	1740200640
Color	Black or Custom Color
Supply Type	OEM/ODM Custom Service
Material	Steel
MOQ	1
Price:	Negotiation

Standard Specification / Undercarriage Parameters

See the full table here

Type	Parameters（mm)					Track Varieties	Bearing(Kg)
Type	A(length)	B(center distance)	C(total width)	D(width of track)	E (height)	Track Varieties	Bearing(Kg)
SJ080	1240	940	900	180	300	rubber track	800
SJ050	1200	900	900	150	300	rubber track	500
SJ100	1380	1080	1000	180	320	rubber track	1000
SJ150	1550	1240	1000	200	350	rubber track	1300-1500
SJ200	1850	1490	1300	250	400	rubber track	1500-2000
SJ250	1930	1570	1300	250	450	rubber track	2000-2500
SJ300A	2030	1500	1600	300	480	rubber track	3000-4000
SJ400A	2166	1636	1750	300	520	rubber track	4000-5000
SJ500A	2250	1720	1800	300	535	rubber track	5000-6000
SJ700A	2812	2282	1850	350	580	rubber track	6000-7000
SJ800A	2880	2350	1850	400	580	rubber track	7000-8000
SJ1000A	3500	3202	2200	400	650	rubber track	9000-10000
SJ1500A	3800	3802	2200	500	700	rubber track	13000-15000

Application Scenarios

1. Crane: construction industry, transport industry, mining, machinery and equipment manufacturing.

2. Spider Lift: decoration engineering , construction, metallurgy, machinery manufacturing.

Design Requirements of Undercarriage

Since the undercarriage has both the support and operation functions,so the design of the undercarriage should meet the following requirements as far as possible:

1) There should be a large driving force, so that the main engine has a good passing performance, climbing performance and steering performance when walking on soft or uneven ground.

2) On the premise of not increasing the height of the undercarriage, the main engine has a larger ground clearance to improve its off-road performance on uneven ground.

3) The undercarriage has a large support area or a small ground pressure to improve the stability of the main engine.

4) There is no sliding or speeding slope slip occurs when the main engine is going down the slope. In order to improve the safety of the main engine.

5) The dimensions of undercarriage should meet the requirements of road transport.

Packaging & Delivery

YIKANG track roller packing: Standard wooden pallet or wooden case
Port : Shanghai or Customer requirements.
Mode of Transportation: ocean shipping, air freight, land transportation.
If you finish the payment today, your order will ship out within the delivery date.

Quantity(sets)	1 - 1	2 - 3	>3
Est. Time(days)	20	30	To be negotiated

One- Stop Solution

Our company has a complete product category which means you can find everything you need here. Such as rubber track undercarriage, steel track undercarriage, track roller、top roller、front idler、sprocket、rubber track pads or steel track etc.
With the competitive prices we offer, Your pursuit is sure to be a time-saving and economic one.
